Magnetic cover lifters

Lightweight and compact manhole opener with a lifting power of 230 to 650 kg.

CL11

CURVE-BASED MAGNETIC COVER LIFTER USABLE IN 3 DIFFERENT WAYS

Universal magnetic lifter with curved base to ensure the best magnetic adhesion on the circumference of circular manhole covers also with “filling” cast iron frame and in asphalt / stone / cement with central metal disc.

The tool can lift also any other common cover or grille in cast iron and ferrous materials. CL11 features an extensible side foot (A) that gives the right lifting geometry and assures full up force when lifting hinged covers with the handle blocked in horizontal position (see the side foot extended in below operation 3). The handle is telescopic and folding to allow ergonomics and minimal space for transport and stocking. The particular tool configuration assures an exclusive versatility of use in 3 different ways. The plate with 18 powerful neodymium magnets gives 420 Kg lifting force with a weight of only Kg 7.


Manual Opening.
Opening with wheeled lever APS90 or APS80.
Opening with horizontally extended handle bar.
Anti-magnetic protective sack
(Cod. A221006)
